Vertiv | NetSure™ 8200 Series -48 VDC Power System Installation Manual (IM582140000) | Rev. A
156
Figure 95:
Load Connections to Power/Distribution Bays Optional Internal Ground (Load Return) Busbar
Assembly
Internal Ground Busbar
Assembly P/N 554862
Internal Ground Busbar
Assembly P/N 555214
Internal Ground Busbar Assembly P/N 555214
Internal Ground Busbars
Mounting Locations
Internal Ground Busbar Assembly P/N 554862
