Vertiv NetSure 8200 Series Installation Manual

Vertiv | NetSure™ 8200 Series -48 VDC Power System Installation Manual (IM582140000) | Rev. A
174
Figure 104: AC Input and AC Input Ground Connections (Lists 105 and 115 Bays, Ten AC Feeds)
Rectifier #1
Rectifier #2
Rectifier #3
Rectifier #4
Rectifier #5
Rectifier #6
Rectifier #7
Rectifier #8
Rectifier #9
Rectifier #10
Front View
Front Door Removed
in Illustration for
Clarity Only
480VAC (List A) or 208VAC (List B), 3 Phase, 60Hz
Ten AC Feeds
Feed #1
Feed #3
Feed #5
Feed #7
Feed #9
Feed #2
Feed #4
Feed #6
Feed #8
Feed #10
A
B
C
A
B
C
A
B
C
A
B
C
A
B
C
A
B
C
A
B
C
A
B
C
A
B
C
A
B
C
Frame
Ground
(1/4-20 Studs
on 5/8" Centers)
(1/4-20 Studs
on 1" Centers)
(1/4-20 Studs
on 5/8" Centers)
