Figure 11: Bolting Power/Distribution Bay to Distribution Only Bay
1st D
ist
ribution Only Bay
ASSEMBLED V
IEWS
B
usb
ar
Pla
tes
1
. Sli
de b
usbar be
twe
en
e
xis
tin
g busbar p
lat
es.
2. Install
these busba
rs.
3. Install
bolts and h
ardwar
e six places (
hand-t
ight).
1/2-13 x 2” Bolts,
1/2” Belleville Lock Washer,
Busbars
Bay Preparation
A. Remove rear cover panels.
B. Remove s ide panels on sides of bays
that will be palced next to each other.
