Vertiv | NetSure™ 8200 Series -48 VDC Power System Installation Manual (IM582140000) | Rev. A
32
Figure 13: Bolting Power/Distribution Bay to Distribution Only Bay
Holes for Bolting
Power/Distribution
Bays and Distribution
only Bays Together
Bay/Bay Sides Bay /Bay Sides
Hardware Build-Up: (use ground washers
in center tie points each side)
Bolt, Ground Washer, Bay/Cabinet Sides,
Ground Washer, Nut
Hardware Build-Up: (use in remaining connection points )
Bolt, Lock Washer, Flat Washer, Bay/Cabinet Sides,
Flat Washer, Lock Washer, Nut
