Chapter 18: Technical
Specifications
Imaging Catheters
Transducer type: Piezoelectric
360° view, multi-element solid state array transducer (except
Revolution)
360° view, single-element rotational transducer (Revolution)
Frequency and available imaging diameters are noted in the table below.
Catheter
Frequency
Imaging Diameters (mm)
Eagle Eye Gold
20 MHz 8, 10, 12, 14, 16, 18, 20
Eagle Eye Platinum
20 MHz 8, 10, 12, 14, 16, 18, 20
Eagle Eye Platinum ST
(Short Tip)
20 MHz 8, 10, 12, 14, 16, 18, 20
Visions PV .014P
20 MHz 8, 10, 12, 14, 16, 18, 20
Visions PV .018
20 MHz 10, 12, 14, 16, 18, 20, 22, 24
Visions PV .035
10 MHz 20, 25, 30, 35, 40, 45, 50, 55, 60
Revolution
45 MHz
8, 10, 12, 14
Pioneer Plus
20 MHz
8, 10, 12, 14, 16, 18, 20
NOTE 1: Additional information is available in the “Physicians Guide and Instructions
for Use” that accompanies each catheter.
NOTE 2: Information about the technical specification for the Revolution catheter, refer
to the Volcano System Revo Option Operator’s Manual.
Video
System Video Display Format
 Display port and DVI/HDMI/VGA adaptors are available
 1280 x 1024 pixel resolution
 60 to 75 Hz refresh
