300004969171/B Page 27 of 148
Workstation (Central Processing Unit)
The workstation or CPU (central processing unit) contains the main system electronics as
well as the inputs and outputs for all the peripheral devices.
NOTE: The workstation model number and electrical ratings are labeled on the rear
panel of the workstation. The workstation model numbers are listed as applicable
throughout the manual.
Printer
A color printer is included with your system to provide high quality color printouts for
your patient’s records. Replacement ink cartridges can be ordered through Volcano or
most major office supply stores.
The printer power switch, located on the printer front panel (see below), is dedicated to
ON/OFF function of the printer only.
Figure 9: Printer Power Switch
Connector Panel
The Connector Panel is designed to provide a flexible intermediary connection platform
for Volcano’s multi-modality system. It offers a manageable interface panel for
connecting bedside peripherals and patient interface modules. There are flexible
mounting schemes to allow adapting the installation to various environments and needs.
Use caution when unplugging a cable from the Connector Panel. See connector types in
the table below. Do not unplug by pulling on the cable.
Power Switch
