Chapter 5: Acquiring IVUS Images
This chapter describes the steps that should be followed for imaging during an IVUS
case. Please refer to the previous chapter for instructions on preparing the system and
catheter.
Overview
The following should be performed during each IVUS case, prior to recording images:
Insert the catheter
Adjust the image (if desired)
Insert the Catheter
The Volcano imaging catheters are designed for placement using standard intra-operative
or percutaneous techniques by suitably trained physicians. The frequency and duration of
administration is subject to the discretion of the physician and depends upon the
procedure and information required.
1 Prepare the patient according to standard catheter lab procedures.
2 Introduce the catheter into the coronary arteries or peripheral vascular system,
placing it onto the previously positioned intravascular guide wire.
3 Advance the imaging catheter to the most distal examination site in the coronary or
peripheral vasculature.
4 Press the Home tab or the Home (Live) key on the control console to display the
Home screen.
