Volcano CORE Mobile User Manual

300004969171/B Page 147 of 148
communication between systems stops. The range for this value is 10 to 600
seconds. The factory default is 60.
 Compression: The following compression selections are available for sending
images to the remote DICOM Storage server:
o No compression
o JPEG High Quality
o JPEG Medium Quality
o JPEG High Compression
 Check Button: This button is used to test the connection between the Volcano
DICOM SCU and the remote DICOM Storage SCP. The connection is tested
using the DICOM C-ECHO service (Verification class).
 US Modality: When checked, images will be transferred to remote storage
servers using the US Modality. When unchecked, images are transferred using
the IVUS Modality.
Worklist Servers Configuration
This section describes the DICOM Configuration Dialog - Worklist Servers
Configuration. The following parameters are configurable for the each defined Remote
DICOM Modality Worklist SCP Server.
 Select Server: Selects the current Server from the Server List for configuration
 New Server: Names a New Server. A server name must be entered in this field
before it can be added to the Server List.
 Add: Adds the New Server to the Server List.
 Delete: Removes the current Server from the Server List.
Figure 61: DICOM Settings-Worklist Servers Dialog Box
