Volcano CORE Mobile User Manual

Page 128 of 148 300004969171/B
Distance Measurement: ± 1% of the measurement ± 0.10mm
Area Measurement: ± 5% of the measurement ± 0.10mm
2
In-Line Digital Measurement Accuracy
 Two distance measurements on the longitudinal display (ILD)
 Maximum Loop Distance (Z axis length) 2700 Frames @ 30 fps & 0.5 mm/sec
pull back -> 45 mm
 Accuracy (Trak Back, R-100 Pull Back ± 5%) @ 30 fps & 1.0 mm/sec pull back
-> 90 mm
 Accuracy (Trak Back, R-100 Pull Back ± 3%)
Accessories and Replacement Parts
NOTE: The Volcano system is compliant to IEC 60601-1-2 with the following
accessories and cabling.
Volcano CORE System
Part Number
Description
Maximum
length/qty
300004969171 (hardcopy)
300004969261 CD
Volcano CORE Mobile Operator’s Manual
N/A
804390001
Large Size (144mm x 100mm), A6 Paper for Sony
UP 25MD 4 packs of 50 sheets N/A
431-0100.01
Small Size (100mm x 90mm), A6 Paper for Sony UP
25MD 3 packs of 80 sheets N/A
431-2800.01 Keyboard Cover N/A
421-1202.09 DVI, Display Port Adaptor
N/A
421-1202.10 HDMI, Display Port Adaptor
N/A
421-1202-11 VGA, Display Port Adaptor
N/A
806452009 Detachable PIM cable
5 meters
806395001 VGA interconnect cable
3 meters
804290001 DVI-D interconnect cable
3 meters
806814001 Joystick ground cable
3 meters
804409001 100-240V AC Power cable
3 meters
421-1202.01 220-240V AC Power cable
3 meters
421-2402.02 Fuse, 12A: 100V isolation transformer setting
2 each
421-2402.01 Fuse, 10A: 120V isolation transformer setting
2 each
805642001 Fuse, 5A: 240V isolation transformer setting
2 each
