300004969171/B Page 29 of 148
Connector Panel Connectors Function Connect
Type
FM PIM-FFR
connection
Push/Pull
IVUS SA PIM
and
SpinVision
(PIMr)
Twist lock
CORE FM Push/Pull
Display Port Push/Pull
USB Push/Pull
Network
connections
(for DICOM
and Image
Export)
Push and
latch/unlatch
and pull
ECG/Aortic
input
connection
Twist lock
Connector
may be used to
accommodate
future system
upgrades
Push/Pull
CORE Control
Pad (CCP)
Push/Pull
