300004969171/B Page 37 of 148
Figure 15: Settings – Archive Defaults
VH-IVUS Tab
The VH-IVUS tab allows you to do the following:
Click VH ON By Default if the VH IVUS images are to be displayed by default
when recording video loops, freezing images, and selecting images for review
from Case Explorer (only applies to Eagle Eye catheter). VH will display only if
VH data is available.
Adjust the Default Opacity Levels for each tissue type. This allows you to
customize the relative prominence of tissue color to be displayed. For example,
you may be most interested in necrotic (red) tissue.
Click NC/DC Only Mode On if you want to display only NC and DC. FF and
FI will NOT be displayed in this mode. (See NC/DC section.)
Click OK to save your selections or click Cancel to disregard selections.
