Disassembly/Assembly Procedures LTC Repair
wc_tx000428gb.fm 150
See Graphic: wc_gr002435
Reassembly:
8.10.10 Grease the adjusting point circle (a) of the main cradle and the bottom
pivot point (b) of the main mast.
8.10.11 Using an appropriate crane or hoist, lift the main mast onto the top of
the generator enclosure. Slide the bottom of the main mast into the
main cradle.
8.10.12 Secure the main mast to the main cradle with the washer and nut (c).
8.10.13 Position the cable clip (d), on the tower supply cable, just below the
lower curled portion of the cable. Then, secure the cable clip to the end
of the main mast.
8.10.14 Thread the tower supply cable through the eyes (e) on the main mast.
8.10.15 Thread the tower supply cable through the clamp (f) at the front of the
machine; leave a loop (g) of cable large enough so there is enough
slack in the cable to raise the mast.
8.10.16 Feed the tower supply cable into the control box and connect the wires
to the appropriate locations (h & i). Refer to the wiring diagram.
Tighten the cable clamp (j), organize the wires with new wire ties (k),
and re-install the control panel cover.
8.10.17 Secure the tower supply cable in the cable clip (l) and secure the cable
clip to the underside of the top enclosure panel.
