6.9 Engine Shuts Down—Flowchart 8A
wc_gr003092
Check engine oil level.
Fill machine
with oil.
Is machine oil
level correct?
Ye s
No
Engine Shuts Down
Connect oil
pressure switch
and/or repair wiring.
Is
oil pressure
switch connected
correctly?
Ye s
No
Check engine
coolant level.
Fill engine with
correct amount and
type of coolant.
Is
engine coolant
level correct?
No
Ye s
Connect coolant
temperature switch
and/or repair wiring.
Is
coolant temperature
switch connected
correctly?
Ye s
No
Refer to the
Caterpillar repair manual.
Call Wacker Service.
Checking oil pressure and
coolant temperature switches
Check wiring of oil pressure
switch.
Check wiring of coolant
temperature switch.
