LTC 4L Operation
wc_tx000543gb.fm 25
3.5 Preparing Trailer for Towing or Lifting
See Graphic: wc_gr001423, wc_gr002166
3.5.1 Check that the mast cradle lock pin (j) is in place and secured with the
safety pin.
3.5.2 Ensure that the tower is completely nested inside the transport cradle
and the pin (t) is secure.
3.5.3 Make sure the doors are properly latched.
3.5.4 Return the outriggers to their travel position. Check that the outrigger
bars and jacks are locked in place.
3.5.5 Crank the rear jack (f) all the way in and rotate it 90°.
The the Light Tower is now ready to lift. For towing, continue.
3.5.6 Use the tongue jack (a) to raise the trailer tongue up and then lower it
over hitch on towing vehicle. Lock the hitch to coupling and attach the
safety chains. Swivel the tongue jack 90° and lock it in place.
3.5.7 Connect the trailer wiring to the towing vehicle. Check the brake, turn,
and tail lights for proper operation.
3.5.8 Position the light fixtures down (k). For rough, off-road transportation
remove bulbs from fixtures to avoid damage.
3.5.9 Check the tire inflation.
3.5.10 Attach a red flag to the end of mast before towing.
CAUTION: Maximum recommended speed for highway towing is 72
km/hour (45 MPH). Recommended off-road towing speed is not to
exceed 16 km/hour (10 MPH) or less depending on terrain.
