LTC Repair Maintenance
wc_tx000427gb.fm 59
4.19 Engine Wiring—Item Number: 0620017, 0620028
Ref. Description Ref. Description
1 Glow plugs 9 Water temperature sensor
2 Starter solenoid 10 Low-oil pressure indicator
3 Starter 11 Fuel solenoid
4 Alternator 12 Diode
5 Hour meter 13 Automatic shutdown
6 Automatic voltage regulator 14 Battery
7 Glow plug indicator 15 15 Amp fuse
8 Ignition switch
