4.14 Engine Control Panel Internal Wiring—Lombardini 1003
Ref. Description Ref. Description
a Key switch d Engine protection
b 15A fuse e Preheating
c 80A fuse f Relay
Wire Colors
B Black R Red Y Yellow Or Orange
G Green T Tan Br Brown Pr Purple
L Blue V Violet Cl Clear Sh Shield
P Pink W White Gr Gray LL Light blue
