Introduction
Label only with parking brake switch without lock
Meaning
Parking brake
Position (1501H-S, 1001)
Control stand
Meaning
Information on raising/lowering the skip
Position (1501H, 1001)
On the engine cover
Meaning
This label shows the following information/regulations:
• Maximum payload of machine.
• Tilt out the raised skip only on horizontal ground.
• Tilt out only in straight machine position.
• Maximum slope inclination allowed for tilting out downhill.
Position (1001)
On the skip
Meaning
This label shows the following information/regulations:
• Maximum payload of machine.
• Do not tilt out the skip if material is stuck in the skip.
Position (1501S)
On the skip
Meaning
This label indicates the maximum authorized angle of inclination for traveling on slopes,
whatever the position of the machine.
Position (2001)
On the skip
Meaning
Skip swivel
Position (1501S, 2001)
On the engine cover
Fig. 17: Parking brake
Fig. 18: Raising and lowering the skip
Fig. 19: Angle of inclination
Fig. 20: Angle of inclination
Fig. 21: Angle of inclination
Fig. 22: Skip swivel
