WAGNER PROTEC 95-150 - Technical Data for Tiger

24
VERSION 01/2020
ORDER NUMBER DOC2340282
IceBreaker 150-300 cm
3
5.5.6 TECHNICAL DATA FOR TIGER
Description Units
Pump ratio 72:1
Volume ow per double stroke ( ) cm; cc 300
Maximum operating overpressure MPa; bar; psi 53; 530; 7687
Maximum possible strokes in operation /min. 40
Maximum recommended strokes per minute in
continuous operation
/min. 30
Minimum/maximum air inlet pressure MPa; bar; psi 0.25–0.74; 2.5–7.4; 36–107
Compressed air quality: free from oil and water
Quality standard 7.5.4 according to ISO 8573.1, 2010
7: Particle concentration 5–10mg/m³
5: Humidity: pressure dew point ≤ 7 °C
4: Oil content ≤ 5mg/m3
Air inlet (inside thread) inch G 1"
Minimum Ø of the compressed air supply line mm; Inch 25; 1.0
Air consumption at 0.6 MPa; 6 bar; 87 psi per double
stroke
nl; scf 170; 6
Air motor piston diameter mm; Inch 300; 11.8
Air motor piston stroke mm; Inch 150; 5.9
Sound pressure level at maximum permissible air
pressure*
82
Sound pressure level at 0.6 MPa; 6 bar; 87 psi air
pressure*
80
Sound pressure level at 0.4 MPa; 4 bar; 58 psi air
pressure*
75
Product inlet (inside thread) mm G1 1/2"
Product output (outside thread) mm M24×1.5
Weight kg; lb 80; 176
Product pH value pH 3.5–9
Maximum product pressure at pump inlet MPa; bar; psi 2; 20; 290
Product temperature 5–80; 41–176
Ambient temperature
Construction and
assembly
5–50; 41–122
Storage -20–60; -4–140
Relative humidity % 10–95 (without condensation)
Allowable inclination for operation ± 10
* A-rated sound pressure level measured at 1 m distance, L pA1m, according to DIN EN 14462: 2005.
Reference measurements have been made by SUVA (Swiss National Accident Insurance Fund).
WARNING
Exhaust air containing oil!
Risk of poisoning if inhaled.
Provide compressed air free from oil and water.
