52
VERSION 01/2020
ORDER NUMBER DOC2340282
IceBreaker 150-300 cm
3
13 ACCESSORIES
13.1 ACCESSORIES FOR PRODUCT OUTPUT
x
B_07643
2
A
23
22
24
1
8
15
16
9
17
17
8
DesignationOrder no.
A Order no., see Chapter 14.2 Piston pump PE/TG (Tiger: PE/L)
1 9992504 Separating agent 250 ml; 250 cc
2 236219 Grounding cable 3 m; 9.8 ft
8 2339900 HP lter DN12 PN530-SSt with carbon steel ball valve
9 2339850 Y-distributor M3/8"NPS, complete
15 2331752 Return tube DN6-G1/4"-100mm-PE
16 -- Pressure relief Relex (see supplement, order no. 2409685)
17 9992831 Loctite 542
22 9985671 Outside thread grommet 1"-NW25
23 9974135 Sealing ring 1"
24 2334958 Regulator lock
= wearing parts
