WAGNER PROTEC 95-150 - PC Heater Set (Option)

31
VERSION 01/2020
ORDER NUMBER DOC2340282
IceBreaker 150-300 cm
3
5.9 PC HEATER SET OPTION
The electric, continuous-ow heater with explosion protection is downstream of the pump.
The coating product can only be heated to maximum 80 °C. The continuous-ow heater is
tted with a temperature limiter.
The temperature is set using the temperature regulator. The coating product temperature
can be read o the thermometer on the coating product output.
Description of heater and thermometer
see heater operating manual (order no. 65860).
Assembly of the PC heater set on the heavy-duty PC trolley:
1. Mount heater (2).
2. Mount heater (2) on trolley (1).
3. Connect heater in accordance with the operating manual.
4. Mount enclosed tting (3) on the uid section's outlet tting.
B_04283
1
3
Molykote
80 Nm; 59 lbft
Molykote
Molykote
2
