WAGNER PROTEC 95-150 - Overview of the PROTEC TC Components (for Version with Stroke Sensor)

57
VERSION 01/2020
ORDER NUMBER DOC2340282
IceBreaker 150-300 cm
3
14.3 OVERVIEW OF THE PROTEC TC COMPONENTS FOR VERSION WITH STROKE
SENSOR
B_07660
3
2
9
1
4
10
Tightening torque pos. 2 and
3
Designation
Order no.
1 Piston pump 2409468 2409469 2409801 2409802 2351204 2351202 2411835
2 Fluid section 2344764 2340007 2343850 2343849 2349174 2349173 2349173
3 Air motor 2411847 2411847 2411848 2411848 2351208 2351208 2411849
4
Connection set for air
motor - uid section
2409464 2409464 2399626 2399626 2399626 2399626 2399626
9
Grounding cable,
complete
236219
10 Molykote DX grease 9992616
Tightening torque for air
motor/uid section
50 Nm;
37 lbft
50 Nm;
37 lbft
70 Nm;
52 lbft
70 Nm;
52 lbft
70 Nm;
52 lbft
70 Nm;
52 lbft
70 Nm;
52 lbft
