61
VERSION 01/2020
ORDER NUMBER DOC2340282
IceBreaker 150-300 cm
3
Assembly instructions
Pos Procedure
8 Stick hook part (velcro) to inside of hood. 'Miranit' adhesive (pos. 107).
9 Stick loop part (velcro) to eece side of the deadening pad. 'Miranit' adhesive (pos. 107).
10 Insert the deadening pad into the hood so that it has a tight t. Fleece side outwards.
19 Stick the entire deadening pad to the connecting part with the eece side outwards. 'Miranit'
adhesive (pos. 107).
36–44 Before assembling apply a little Tecni oil (pos. 108) to the housing bore of pos. 31.
Do not dismount the piston of the spool and sleeve assembly (pos. 37).
Grease all O-rings with Mobilux EP2 (Pos 102)
Do not dismount the piston of the spool and sleeve assembly (pos. 37).
Spare parts list
Order no. Designation
1a 1 2411847 Air motor 10", complete for PROTEC 95-150
1b 1 2411848 Air motor 10", complete for PROTEC 72-200
1c 1 2351208 Air motor 10", complete for PROTEC 60-240
1d 1 2411849 Air motor 10", complete for PROTEC 60-240 270 bar
2 1 9900150 Hexagon screw without shaft
3 1 369324 Shoulder ring
4 1 369325 Lifting eye nut
5 1 9925034 Washer
6 1 2353725 Wagner Protec 10 label
7 1 369311 Hood 9
8 2 9999151 Velcro fastener adhesive part
9 2 9999152 Velcro fastener coating part
10 1 369319 Sound deadening pad 9
11 1 369318 Shoulder screw 9
12 7 9907125 Screw SFS Plastite 45
13 2 9925031 Washer 6,4
14 1 369310 Silencer 9
15 1 9974165 O-ring
16 3 9900314 Hexagon socket head cap screw, M8X35
17 3 9925029 Washer 8,4
18 1 369309 Connecting part 9
19 1 369330 Sound deadening pad 9/12"
20 2 9974132 O-ring
21a 1 2409445 Safety valve 6.0 bar for PROTEC 95-150
21b 1 2302480 Safety valve 7.8 bar for PROTEC 72-200
21c 1 368288 Safety valve 8.4 bar for PROTEC 60-240
21d 1 2411749 Safety valve 5.0 bar for PROTEC 60-240 270 bar
22 1 9992718 Angular plug connection
23 2 369026 Air hose
24 2 9998993 Straight screw-in ttings
25 2 369290 Pilot valve
25a 2 9974217 Rod seal
26 2 369312 Outlet seal 9
27 1 3159464 Y-plug connection
28 1 9982078 Hose 8x1 L=42mm
29 1 9992757 Male stud elbow, 8-1/8
= wearing parts
= Included in service set
= Not part of the standard equipment but available as a special accessory.
