WAGNER PROTEC 95-150 - Page 73

73
VERSION 01/2020
ORDER NUMBER DOC2340282
IceBreaker 150-300 cm
3
- only 2K
DesignationOrder no. Order no. Order no.
5 1 368555 Piston
6 1 368506 Valve screw
7 1 2352729 Ball guide, inlet
8 1 368551 Connecting ange
9 1 368509 Valve seat, inlet
10 1 368510 Valve seat, outlet
11 1 368561 Snap ring ange
12 2 368512 Snap ring half
13 1 368513 Securing ring
16 1 368516 Support ring
17 1 367519 Pressure ring
18 1 368518 Support ring
19 1 368519 Pressure ring
100
1 367991 / / Packing PE/TG, complete (small)
1 / 367993 / Packing PE/L, complete (small)
101 1 / / 367992 Packing PE/T, complete (small)
20
2 367522 / / Sealing collar TG (small)
2 / 367922 Sealing collar L (small)
2 / / 367900 Sealing collar T (small)
21 3 367523 Sealing collar PE (small)
103
1 368991 / / Packing PE/TG, complete (large)
1 / 368993 / Packing PE/L, complete (large)
104 1 / / 368992 Packing PE/T, complete (large)
22
2 368522 / / Sealing collar TG (large)
2 / 368922 / Sealing collar L (large)
2 / / 368900 Sealing collar T (large)
23 3 368523 Sealing collar PE (large)
25 2 368525 O-ring
27 1 368527 O-ring
28 1 368528 O-ring
29 1 9999229 Pressure spring
40 1 9998670 Wave spring (small)
41 1 9998671 Wave spring (large)
42 1 9943082 Ball (large)
43 1 9941512 Ball (small)
44 1 9974092 O-ring
46 1 9974107 O-ring
50 3 9907142 Hexagon screw
51 3 9925011 Washer
60 1 9998808 Mobilux EP 2 grease
61 1 9992609 Anti-seize paste tube
62 1 9992616 Molykote DX grease
106 1 2329922 Fitting SF-MM-G3/8"-M24x1.5-PN530-SSt
Service-Sets
1 368990 / / Service set PE/TG
1 / 2342071 / Service set PE/L
1 / / 368994 Service set PE/T
A 1 2413778 / / Sealing set PE/TG
Wearing parts
Included in service set. (For more parts, see Chapter 14.6.5.)
