WAGNER PROTEC 95-150 - Page 75

75
VERSION 01/2020
ORDER NUMBER DOC2340282
IceBreaker 150-300 cm
3
Pos K Stk
200 cm
3
240 cm
3
Designation
PE / TG PE/L PE/T PE / TG PE/L PE/T
Order no. Order no. Order no. Order no. Order no. Order no.
10 1 2336695 Valve seat, outlet
11 1 2336689 Snap ring ange
12 2 2336785 Snap ring half
13 1 2336690 Securing ring
16 1 2336670 2346767 Support ring
17 1 2336680 2346789 Pressure ring
18 1 2336686 2346780 Support ring
19 1 2336694 2346774 Pressure ring
20 1 2386283 Pressure spring
100
1 2341473 / / 2353071 / /
Packing PE/TG,
complete (small)
1 / 2342073 / / 2353072 /
Packing PE/L,
complete (small)
101 1 / / 2345985 / / 2353074
Packing PE/T,
complete (small)
20
2 2336679 / / 2346790 / / Sealing collar T (small)
2 / 2341945 / / 2353078 / Sealing collar (small)
2 / / 2343776 / / 2348802 Sealing collar T (small)
21 3 2336674 2346791
Sealing collar PE
(small)
103
1 2341474 / / 2353075 / /
Packing PE/TG,
complete (large)
1 / 2342074 / / 2353076 /
Packing PE/L,
complete (large)
104 1 / / 2345986 / / 2353077
Packing PE/T,
complete (large)
22
2 2336688 / / 2346778 / / Sealing collar T (large)
2 / 2341943 / / 2353079 / Sealing collar (large)
2 / 2343775 / 2348801 Sealing collar T (large)
23 3 2336687 2346779
Sealing collar PE
(large)
25 1 369527 O-ring
26 1 2336684 2346782 O-ring
27 1 9974194 O-ring
28 1 2338256 O-ring
40 1 2338091 Wave spring (small)
41 1 2338092 Wave ring (large)
42 1 9943086 Ball (large)
43 1 9941513 Ball (small)
44 1 9974132 O-ring
46 1 2336683 O-ring
50 3 9907142 Hexagon screw
51 3 9925011 Washer
60 1 9998808 Mobilux EP 2 grease
61 1 9992609 Anti-seize paste
62 1 999261 Molykote DX grease
106 1 2337413
Fitting SF-MM-G1/2"-
M24-PN530-SSt
= Wearing part
Included in service set. (For more parts, see Chapter 14.6.5.)
