WAGNER PROTEC 95-150 - Page 78

78
VERSION 01/2020
ORDER NUMBER DOC2340282
IceBreaker 150-300 cm
3
- 2K
DesignationOrder no. Order no.
1 1 2340009 -- Fluid section 300 cm
3 1 369516 Support ring 35.8/52-300
4 3 368523 Sealing collar PE 35.8/52
5
2 368922 Sealing collar L 35.8/52
2 / 368900 Sealing collar T 35.8/52
6 1 368519 Pressure ring 35.8/52
7 1 9998671 Spiral wave spring, crest-to-crest 35.8/52
8 2 369512 Snap ring half 300
9 1 369513 Securing ring 300
10 2 369525 O-ring
11 1 370503 Cylinder 300
12 1 370511 Snap ring ange 300
13 1 9974118 O-ring
14 1 369518 Support ring 34/50-300
15 3 369523 Sealing collar PE 34/50
16
2 369922 / Sealing collar L 34/50
2 / 369900 Sealing collar T 34/50
17 1 369519 Pressure ring 34/50
18 1 9998671 Spiral wave spring, crest-to-crest 35.8/52
19 1 369510 Valve seat outlet 300
20 1 9971470 O-ring
21 1 370505 Piston 300
22 1 370506 Valve screw 300
23 1 370514 Shoulder ring 300
24 1 9941505 Ball
25 1 370501 Connecting ange
26 1 370502 Tube 300
27 4 9907210 Hexagon screw
28 4 9920110 Washer
29 1 9974117 O-ring
30 1 2386282 Ball guide
31 1 369509 Valve seat inlet 300
32 1 369527 O-ring
33 1 2338595 Inlet housing 300
34 1 9943086 Ball
35 1 2386283 Pressure spring
40 1 2329923 Rotary connection G3/4"
60 1 9998808 Mobilux EP 2 grease
61 1 9992609 Anti-seize paste tube
62 1 9992616 Molykote DX grease
Packing, upper:
100
1 368993 / Packing PE/L, complete
1 368992 Packing PE/T, complete
Packing, lower:
103
1 369993 Packing PE/L, complete
1 / 369992 Packing PE/T, complete
Service sets:
370989 / Service set 300 PE/L
/ 369964 Service set 300 PE/T
= Wearing part
Included in service set. (For more parts, see Chapter 14.6.5.)
