Hardware Maintenance

Look at the linear slide from above and you will either find a small threaded hole with a

tiny black grub screw (requires a 1.5 mm Allen key) or a visible black Allen screw

(requires a 2 mm Allen key).

1. Remove the screw completely and

carefully put it aside.

2. Screw in by hand the small silver

grease nipple with some revolutions,

which you received with the delivery

of the machine.

3. Place the grease gun, which you

received with the delivery of the

machine, on the nipple and slowly

press grease into the slide with one

or two strokes.

4. Clean the area with a cloth, should

some grease have gone off.

5. Remove the grease nipple and keep

it clean and safe for the next use.

6. Turn the previously removed screw

back using an Allen key.

7. Repeat this procedure about every

100 km of running performance, or if

you have the impression that the

slide may run dry and rough. Better

too often than too rarely!
