4.3.2
Spiral Cable Disconnection
Disconnect the spiral cable from the control
cabinet and slide (A).
To do this, lift the black locking clip on each
socket, remove the plug and place the
cable in its transportation bag.
Power Cable Disconnection
Disconnect the power cable (B) from the
power outlet and from the rear left jack of
the platform.
To remove the power cord, pull up the
small locking lever (1), turn the plug
housing 45 degrees counterclockwise (2),
