Assembly
... and keep the "Brake Release Button"
pushed while pulling the slide unit up for
about 25 cm as shown on the left.
Turn the power switch to OFF.
Place the print-head at the front end of the
axis across profile, hold it in place and
lead it sideways onto the two guiding pins.
