Place the printhead on a clean and level
surface.
Open the left front flap to close the tube
clamps to prevent ink leakage during
transport.
Gently squeeze all clamps as shown until
you hear exactly 4 clicks...
(You may occasionally move them on the
hose by a few millimeters so that the hose
is not always pushed off in exactly the same
place.)
Close the left front flap and clean the front
around the the printheads carefully with a
soft cleaning wipe.
Protect the printheads from damage and
light exposure with the magnetic front
cover.
Only in case the cross profile extension is
attached and no matter in which of the two
possible positions the cross profile
extension is mounted, proceed according
to this principle when disassembling it:
· Loosen the two screws as shown in the
figure on the left.
· Carefully pull the extension sideways from
the locating pins and stow it in its
transportation bag.
