wallPen E2 | User Manual
82
Operation
Procedure on the printer
24. Make sure - especially in the area of fading - that the floor is level. If the floor in this
area is uneven, the print will not be clean and the transition may be visible later.
25. Mount the print head on the left (= rear) side of the wallPen.
26. Align the wallPen precisely and parallel to the wall
27. Load and print the file processed image "left".
28. Find the small mark at the bottom of the printed image at the beginning of the
fading.
29. Proceed with this marking in the image as described in the previous chapter
"Operation | Working with the Reference Point". Mark the reference point with a
pencil.
30. Mount the printhead on the right (= front) side of the wallPen.
31. Now push the printer back so far that the laser dot is in the area of the reference
point mark.
32. Now position the wallPen as exactly as possible with the laser dot in the pencil
mark. Make sure that the device is again very precisely parallel to the wall.
33. Load and print the file processed image "right".
