Making Screw Terminal Connections with External Devices 47
• If you use a non-IEEE-488 autosampler, the autosampler provides the inject start
signal to trigger both the 600 controller and Waters 746. Both the autosampler and
the Waters 746 connect to the 600 controller Inject terminal (Figure 3-10).
Note: When you connect the Waters 746 to the 600 controller, you must also attach
an RS-232 interface cable between the 600 controller and the 746. Refer to
Section 3.4, Making RS-232 Connections with the Waters 746 Data Module.
Connections
Connect the Waters 746 to the 600 controller (using the Remote Start cable) as described
below:
Figure 3-9 illustrates connecting the Waters 746 to the 600 controller Inject signal.
Figure 3-10 illustrates connecting both the Waters 746 and a non-IEEE-488 autosampler
to the 600 controller Inject signal.
Waters 746
Connection
600 Controller
Connection
Autosampler
Connection (if
applicable)
DIN plug (single
3-pin connector):
ARS (White) - Channel A
or
BRS (Red) - Channel B
GND (Green) - Ground
Inject and Gnd Inject Start or Integ Start
