November 16, 2016, 715004521 Rev. C
Page 73
Table 5–13: Core 4 configuration with a PDA, SQD, and splitter
Tube Tube description From To ID
Notes:
recommended
trim length
1 29.5 inch
PEEKsil tubing
(pre-connected to
the splitter)
Splitter module Mass spectro-
meter
50 µm Do not trim
250 inch
PEEK tubing
(pre-connected to
the splitter)
Splitter module Left side of the
ccManager tee
0.010 inches Do not trim
more that
8 inches
359 inch
PEEK tubing
(pre-connected to
the splitter)
Top of the
PEEK union
on the 515
makeup pump
Splitter module 0.005 inches Trim as needed
446 inch
PEEK tubing
(pre-connected to
the splitter)
CM-30S or
PDA
Splitter module 0.007 inches Do not trim
more that
8 inches
