Wavetronix SmartSensor HD - Page 97

96
•
SmartSensor HD User Guide
Setting Description Details
All three pushed data types
HD Native SmartSensor
HD (SS125) format.
Use this for a
standard SmartSensor
HD system.
SS105 Simple Emulates the original
SmartSensor (SS105)
format, without a
multi-drop header.
Use this when
you’re using the
SmartSensor HD
in a system that
was designed for a
SmartSensor 105.
SS105 Multidrop Emulates the original
SmartSensor (SS105)
format, with a multi-
drop header.
Use this when
you’re using the
SmartSensor HD
in a system that
was designed for a
SmartSensor 105.
Event data only
Z4 2-Loop Emulates a dual-
loop system. Speed
and duration are
measured using the
loop size and spacing
set in the Loop
Emulation settings.
Use this when
you’re using the
SmartSensor HD in
a system that was
designed for dual
inductive loops.
Z4 1-Loop Emulates a single-
loop system. Duration
is measured using
the loop size set in
the Loop Emulation
settings.
Use this when
you’re using the
SmartSensor HD in
a system that was
designed for single
inductive loops.
Z4 2-Loop Pulsed Emulates a dual
loop system; outputs
will be held active
for 125 ms for each
vehicle detected, so
only speed will be
measured.
Use this when
you’re using the
SmartSensor HD in
a system that was
designed for dual
inductive loops and
all you need is vehicle
presence and speed.
Definition. Z4 is a
Wavetronix-specific
protocol that lets
sensors talk to other
Wavetronix devices,
mostly contact
closure devices.
Note. The Loop
Emulation settings
are found on the
Settings screen and
covered in chapter 5.
