For the connection can be used: a standard cable with M8 connec-
tor (art. no: 72901034), or a splitter cable (art no.: 72901036) in
conjunction with an M8 Extension (art no.: 72901040).
Angled connectors can be used in crowded spaces. Therefore is a
50 cm extension with angled connector M8 and straight socket
available: (Art.no.:718000117).
When using the splitter cable are both inputs / outputs clearly
separated.
The output is on a socket on PIN4 (see Fig. 29).
