8.12 Setting zoom
The width of the print image can be varied with the zoom value. At
a zoom of 100%, the print image is printed 1:1 as displayed in the
iDesign.
With this parameter a change in the size of the print image is
achieved. If the parameter is reduced the print image becomes
narrower by delaying individual pixel gaps. This compresses the
pint image and enables the ink consumption to be reduced.
NOTE!
By printing of barcodes you must look out for print
optimal with 300 dpi and 100%. Other dpi values or
an enlarging or narrowing can cause deformations.
With the standard setting the print image has the same width,
irrespective of the modified intensity (dpi).
100% = 1:1
Via WEB-interface or iDesign it is possible to select the “Fixed
zoom”. The print image will be print with all pixel, irrespective of the
intensity.
The print image is in the width 1:1 with a resolution of 600 dpi.
With a resolution of 300 dpi, the print image is more than twice the
width 1:2, caused of the halved intensity.
Change the zoom to 10% - 900% with the iLOGIK. The value can be changed in 1% steps.
Pay attention, that a widening or narrowing of barcode prints have the right measure.Follow the chart.
Barcode width: Allowed Zoom factors with fixed zoom:
1 100 200 300 400 500 600 ...
2 50 100 150 200 250 300 350 ...
3 33 66 100 133 166 200 233 266 ...
4 25 50 75 100 125 150 175 200 225 ...
5 40 60 80 100 120 140 160 180 200 ...
6 33 50 66 83 100 116 133 150 166 183 ...
