Weber Markoprint iJET - Interfaces; Ethernet

Art. No.: 72801001
Appendix
Page 114 of 127
13.15 Interfaces
13.15.1 Ethernet
 Connection
RJ 45 at Power supply.
PIN
Description
1
Transmit+
2
Transmit-
3
Receive+
6
Receive-
 Connection
Connect network input M12 to the iJET system unit.
PIN
Description
Voltage
1
Transmit+
V+
2
Receive+
V-
3
Transmit-
V+
4
Receive-
V-
Connection cable M12 to RJ45 3m long drag chain suitable
(Art.no.:72901030)
Connection cable M12 angled to RJ45 5m long (Art.no.:72901037)
Power supply with angled connection cable (Art.no.:72801024)
