Weber Markoprint iJET - Usb a; Jumper Sensor

Art. No.: 72801001
Appendix
Page 115 of 127
13.15.2 USB A
The USB sockets are standard sockets, as used in commercial
PCs and USB devices.
Insert the USB plug vertically into the USB socket without using
force.
PIN
Name
Colour
Description
1
VCC
Red
+5 V
2
D-
White
Data -
3
D+
Green
Data +
4
GND
Black
Mass
13.15.3 Jumper sensor
CAUTION!
The jumpers may only be resoldered by the
manufacturer or by trained specialized personnel.
Sensitivity of internal sensor:
The sensitivity of the internal sensor can be compensated for with
jumpers 15 and 16. The higher the resistance selected the more
sensitive.
JP 15
JP 16
Value Resistance
Unit
open
open
114
ohms
closed
open
57
Ohms
open
closed
78
Ohms
closed
closed
46
Ohms
