Page 36 of 127
5.7 Flexible Bracket (Flexbracket)
The Flexbracket is an optinal available mounting bracket, which
adjust a variable distance up to 20 mm between print system and
product. The print system is provided with a special formed
deflector and a linear movable bracket.
The print system is mounted on the production line that the product
hit the deflector. The print system is pressed in position, against
the spring power of the Flexbracket. After the product passes the
print system moves the print system by spring power back in
starting position.
The Flexbracket should use for print speeds up to 20 m/min.
For higher speeds is a constant guide not guaranteed and the
print result can be manipulate negative.
Fig. 4: Print systemt
