Wecon VD2 SA Series Servo Drives Manual (Lite V1.1)
WECON technology Co., Ltd
28
(4) VD2F drive single-phase 220V main circuit wiring
ALM
ALM
MC
OFF
ON
M
Motor
External brake resistor
MCCB
MC
L1
L2
Power
(Single-phase)
AC220V 50Hz
Noise ?lter
L
Incoming line
Power input
C
D
U
V
W
DOCOM
P+
Motor output
Short wire
External brake resistor


Insulated
power
DC12V~24V
5%)
Red
Yellow
Blue
Yellow-green
Inductive surge absorber
※
ALM is output from Do2 by fault
Can be con?gured by function code
PE
D02
reactor
( )Internal temperature control switch
Figure 4-7 VD2F drive single-phase 220V main circuit wiring
