Wecon VD2F-010SA1P - Page 71

Wecon VD2 SA Series Servo Drives Manual (Lite V1.1)
WECON technology Co., Ltd
65
P01-24
Parameter name
Setting method
Effective time
Default
Range
Category
Unit
Internal speed
Instruction 2
Operation
setting
Effective
immediately
0
-3000 to 3000
Speed
mode
rpm
-5000 to 5000*
Used to set the speed value of internal speed instruction 2. “*” indicates the setting range of VD2F servo drive.
P01-25
Parameter name
Setting method
Effective time
Default
Range
Category
Unit
Internal speed
Instruction 3
Operation
setting
Effective
immediately
0
-3000 to 3000
Speed
mode
rpm
-5000 to 5000*
Used to set the speed value of internal speed instruction 3. “*” indicates the setting range of VD2F servo drive.
P01-26
Parameter name
Setting method
Effective time
Default
Range
Category
Unit
Internal speed
Instruction 4
Operation
setting
Effective
immediately
0
-3000 to 3000
Speed
mode
rpm
-5000 to 5000*
Used to set the speed value of internal speed instruction 4. “*” indicates the setting range of VD2F servo drive.
P01-27
Parameter name
Setting method
Effective time
Default
Range
Category
Unit
Internal speed
Instruction 5
Operation
setting
Effective
immediately
0
-3000 to 3000
Speed
mode
rpm
-5000 to 5000*
Used to set the speed value of internal speed instruction 5. “*” indicates the setting range of VD2F servo drive.
P01-28
Parameter name
Setting method
Effective time
Default
Range
Category
Unit
Internal speed
Instruction 6
Operation
setting
Effective
immediately
0
-3000 to 3000
Speed
mode
rpm
-5000 to 5000*
Used to set the speed value of internal speed instruction 6. “*” indicates the setting range of VD2F servo drive.
P01-29
Parameter name
Setting method
Effective time
Default
Range
Category
Unit
Internal speed
Instruction 7
Operation
setting
Effective
immediately
0
-3000 to 3000
Speed
mode
rpm
-5000 to 5000*
Used to set the speed value of internal speed instruction 7. “*” indicates the setting range of VD2F servo drive.
P01-30
Parameter name
Setting method
Effective time
Default
Range
Category
Unit
Delay from brake
output ON to
instruction reception
Operation
setting
Effective
immediately
250
0 to 500
-
rpm
Set the delay time from the brake (BRK-OFF) output is ON to the servo drive allows to start receiving input
instructions. When the brake output (BRK-OFF) is not allocated, this function code has no effect. Please refer to
full version manual V1.1 “6.1.8 Brake device”.
P01-31
Parameter name
Setting method
Effective time
Default
Range
Category
Unit
Stationary state. delay from
the brake output is OFF to
the motor is not energized
Operation
setting
Effective
immediately
150
1 to
1000
-
rpm
When the motor is in a static state, set the delay time from the brake (BRK-OFF) output is OFF to the servo drive is in
the non-powered state. When the brake output (BRK-OFF) is not allocated, this function code has no effect. Please
refer to full version manual V1.1 “6.1.8 Brake device”.
P01-32
Parameter name
Setting method
Effective time
Default
Range
Category
Unit
Rotation state: when the
brake output is OFF, the
speed threshold
Operation
setting
Effective
immediately
30
0 to
3000
-
rpm
The motor is rotating, the motor speed threshold when the brake (BRK-OFF) is allowed to output OFF. When the
brake output (BRK-OFF) is not allocated, this function code has no effect.
Please refer to full version manual V1.1
“6.1.8 Brake device”.
