Wecon VD2 SA Series Servo Drives Manual (Lite V1.1)
WECON technology Co., Ltd
93
U0-35
Monitoring name
Range
Category
Panel display
Unit
Data type
Total operation time (hour)
-
Universal
Decimal
h
16-bit
U0-37
Monitoring name
Range
Category
Panel display
Unit
Data type
Total operation time (minutes)
-
Universal
Decimal
min
16-bit
U0-38
Monitoring name
Range
Category
Panel display
Unit
Data type
Total operation time (seconds)
-
Universal
Decimal
s
16-bit
U0-39
Monitoring name
Range
Category
Panel display
Unit
Data type
Load torque percentage
-
Universal
Decimal
%
16-bit
Display current load torque percentage. If the current load torque percentage is 10.3%, the panel of servo drive
is displayed as below.
U0-40
Monitoring name
Range
Category
Panel display
Unit
Data type
Current operation time (hour)
-
Universal
Decimal
h
16-bit
U0-42
Monitoring name
Range
Category
Panel display
Unit
Data type
Current operation time (minutes)
-
Universal
Decimal
min
16-bit
U0-43
Monitoring name
Range
Category
Panel display
Unit
Data type
Current operation time (seconds)
-
Universal
Decimal
s
16-bit
U0-44
Monitoring name
Range
Category
Panel display
Unit
Data type
Instantaneous braking resistor power
-
Universal
Decimal
W
16-bit
U0-46
Monitoring name
Range
Category
Panel display
Unit
Data type
Average braking resistor power
-
Universal
Decimal
W
16-bit
U0-48
Monitoring name
Range
Category
Panel display
Unit
Data type
Power-on times
-
Universal
Decimal
Times
16-bit
U0-50
Monitoring name
Range
Category
Panel display
Unit
Data type
Motor cumulative number of turns
(low 32 bits)
0 to 2
32
-1
Universal
Decimal
Cycles
32-bit
U0-51
Monitoring name
Range
Category
Panel display
Unit
Data type
Motor cumulative number of turns
(high 32 bits)
0 to 2
32
-1
Universal
Decimal
Cycles
32-bit
U0-53
Monitoring name
Range
Category
Panel display
Unit
Data type
Motor model code
-
Universal
Hexadecimal
-
16-bit
Display current Motor model code. Take WD80M-07530S-A1F (A026) as an example, the panel of servo drive is
displayed as below.
U0-54
Monitoring name
Range
Category
Panel display
Unit
Data type
Absolute encoder
position within 1 circle
0 to 2
32
-1
Universal
Decimal
Encoder unit
32-bit
Display the single turn position feedback value of absolute encoder
