Wega Wegaconcept

52
Wegaconcept
Technical manual
i
The alarm view and reset functions are enabled
ONLY for the technician.
30 Schedules maintenance
30.1 Alarm display
This function permits verication of the last 8 alarms
detected by the machine.
ENTER
(x 5 secs.)
Hold down the ENTER button for at least 5 seconds.

Scroll the menu until the item is highlighted
09 FILTER REGENERAT.
10 COUNTERS
11 CLOCK SETUP
12 WORKING DAYS
ENTER Conrm to access the menu
TOTAL COFFEES
XXXXXXXX

Press () or () to display the last 8 alarms memo-
rized by the system
XX - DDMMYY XX - DDMMYY
XX - DDMMYY XX - DDMMYY
XX - DDMMYY XX - DDMMYY
XX - DDMMYY XX - DDMMYY
XX
Alarm code.
DDMMYY
Last alarm date
To reset the alarms proceed as follows.
XX - DDMMYY XX - DDMMYY
XX - DDMMYY XX - DDMMYY
XX - DDMMYY XX - DDMMYY
XX - DDMMYY XX - DDMMYY

The alarms can be reset by pressing the button () for
at least 3 seconds.
RESET ALARMS?
PRESS KEY ^ 3 SEC

conrm by pressing () for 3 seconds.
Alarms code table:
Code Alarm description
1 Heat sensor group open on group 1
2 Heat sensor group open on group 2
3 Heat sensor group open on group 3
4 Heat sensor group open on group 4
5 Check heating circuit group on group 1
6 Check heating circuit group on group 2
7 Check heating circuit group on group 3
8 Check heating circuit group on group 4
9 Water heat sensor open on group 1
10 Water heat sensor open on group 2
11 Water heat sensor open on group 3
12 Water heat sensor open on group 4
13 Check water heat sensor on group 1
14 Check water heat sensor on group 2
15 Check water heat sensor on group 3
16 Check water heat sensor on group 4
17 Steam boiler sensor open
18 Steam boiler heat circuit
19 Cup heater: sensor disconnected
20 Cup heater: sensor short circuit or excessive temperature
21 Autosteamer: sensor disconnected
22 Cup heater: sensor short circuit or excessive temperature
23 Steam boiler heating timeout
24 Heating group timeout on group 1 - Machine start
25 Heating group timeout on group 2 - Machine start
26 Heating group timeout on group 3 - Machine start
27 Heating group timeout on group 4 - Machine start
28 Heating group out of service on group 1 - Machine running
29 Heating group out of service on group 2 - Machine running
30 Heating group out of service on group 3 - Machine running
31 Heating group out of service on group 4 - Machine running
32 Coee water heater timeout on group 1 - Machine start
33 Coee water heater timeout on group 2 - Machine start
34 Coee water heater timeout on group 3 - Machine start
35 Coee water heater timeout on group 4 - Machine start
36 Coee water heating coee water on group 1 - Machine running
37 Coee water heating coee water on group 2 - Machine running
38 Coee water heating coee water on group 3 - Machine running
39 Coee water heating coee water on group 4 - Machine running
40 Filling timeout. First coee boiler/steam lling 255"
41
Filling timeout. Top o steam boiler level 90"(180"for coee boiler)
42 Safety level. Steam boiler
43 Coee water pressure group 1. Pressure timeout.
44 Coee water pressure group 2. Pressure timeout.
45 Coee water pressure group 3. Pressure timeout.
46 Coee water pressure group 4. Pressure timeout.
47 Volumetric dosing device 1
48 Volumetric dosing device 2
49 Volumetric dosing device 3
50 Volumetric dosing device 4
51 Water softener regeneration
