Wegaconcept
Technical manual
Beverages selection codes table
Description Signal
1 Espresso GR1 011 h
1 Medium GR1 012 h
1 Large GR1 013 h
2 Espressos GR1 014 h
2 Medium GR1 015 h
2 Large GR1 016 h
1 Espresso GR2 021 h
1 Medium GR2 022 h
1 Large GR2 023 h
2 Espressos GR2 024 h
2 Medium GR2 025 h
2 Large GR2 026 h
1 Espresso GR3 031 h
1 Medium GR3 032 h
1 Large GR3 033 h
2 Espressos GR3 034 h
2 Medium GR3 035 h
2 Large GR3 036 h
1 Espresso GR4 041 h
1 Medium GR4 042 h
1 Large GR4 043 h
2 Espressos GR4 044 h
2 Medium GR4 045 h
2 Large GR4 046 h
Tea 1 051 h
Tea 2 052 h
35.3 DEBIT - CREDIT system with
connection to the INTERFACE
The DEBIT-CREDIT system allows beverages to be
paid for after they have been delivered, as the doses
are recorded by the coee machine’s cash register. The
procedure is possible thanks to the interface between
the coee machine and the cash register.
In particular, the system is structured as follows:
Installation
The CREDIT-DEBIT function is available on electronic
control units with software program dated 06/03/08 or
later.
For installation proceed as follows:
t Turn the machine o;
t place the switch no. 11 of the SW2 micro-switch
battery in the ON position, as shown in the electrical
diagram on the next page;
t connect the supplied CA cable (code 22554011) from
the CN13 dedicated connector of the CE electronic
board (cod.18090099); to the CN3 connector of the
IN interface;
t connect the CS serial cable (code 22554010) from the
CN4 dedicated connector of the CE electronic board
to the CN8 connector of the IN interface;
t connect the CH hartwall cable (code 22554004)
between the connector of the IN interface and the
cash register;
t position the JP1 and JP2 jumpers on the IN interface,
as shown in the following diagram
t close the JP5 jumper on the IN interface;
t start the machine again.
I/O Interface
Beverages are delivered
by the coee machine.
Beverage deliveries are
recorded by the
cash register.
i
The management software of the register and
the of the hartwall CH at the register, are not the
responsibility of the manufacturer The switch of the
IP interface can't be in PROG. position
