74
Wegaconcept
Technical manual
Water Group Relay I/O CONNECTOR
1 Espresso 1 1 CN7-1
1 Medium 1 2 CN7-2
1 Large 1 3 CN7-3
2 Espressos 1 4 CN7-4
2 Medium 1 5 CN7-5
2 Large 1 6 CN7-6
1 Espresso 2 7 CN7-7
1 Medium 2 8 CN7-8
1 Large 2 9 CN7-9
2 Espressos 2 10 CN7-10
2 Medium 2 11 CN7-11
2 Large 2 12 CN7-12
1 Espresso 3 13 CN7-13
1 Medium 3 14 CN7-14
1 Large 3 15 CN7-15
2 Espressos 3 16 CN7-16
2 Medium 3 17 CN7-17
2 Large 3 18 CN7-18
1 Espresso 4 19 CN7-19
1 Medium 4 20 CN7-20
1 Large 4 21 CN7-21
2 Espressos 4 22 CN7-22
2 Medium 4 23 CN7-23
2 Large 4 24 CN7-24
Tea 1 25 CN7-25
Tea 2 26 CN7-26
CN7-33 I/O enabling
CN7-35 I/O enabling
CN7-37 com. relay
CN7-38 com. relay
CN7-39 com. relay
CN7-40 com. relay
CE electronic central unit PLUS4 cod. 18090099
* CA Power supply cable 06.00.413 cod. 22554011
* CH Hartwall cable 8.9.28.51 code 22554004
CN3 Power supply connector 12V DC interface
CN13 Control unit serial cable connector
CN8 Interface serial cable connector
CN6 Power supply connector 12V DC control unit
* CC Connect. cable serial transmission AMP L 550 cod. 22554012
* CI Interface cable 32 relay cod. 22554002
* CS Serial transmission cable code 22556004.
* IN Interface 32 relay cod. 26016
IP Programming switch
SW Control unit micro-switches
BM Machine edge
33 - 35 Jumper for MACHINE - INTERFACE communication testing
B White
N Black
R Red
V Green
MBrown
G Yellow
JP Jumper (jumpers)
* Kit Cod.: 83260063R
