6.1.12 Parameter Setting of SANYO PY Servo Driver
Para.
No.
Abbr.
Name
Standard
Value
Setting
Range
Unit
Remark
1-2
EGER
Electronic
gear ratio
4/1
1/32767
to
32767/1
Depends on the specific encoder
resolution. The formula of
electronic gear ratio of servo
driver is as below:
Electronic gear ratio numerator
=mechanical deceleration ratio ×
pulse No. per encoder circle;
Electronic gear ratio denominator
= (screw pitch / pulse equivalent)
E.G. In Weihong system, the
default pulse equivalent is
0.001mm/p, screw pitch is 5mm,
pulse number per encoder circle
is 2000 shaft coupling direct drag,
currently the numerator of the
electronic gear ratio is 8, and the
denominator is 5. (Select
incremental type encoder)
1-16
MENP
Pulse amount of the
motor encoder
1. Set the pulse amount
of the motor encoder;
2. Standard
configuration of the
encoder pulse No. is as
below.
Incremental encoder
omitting wiring:
--2000P/R
Absolute
encoder:--2048P/R
500
to
65535
P/R
2-0
PMOD
Pulse format of position command:
Our system uses: direction + pulse format, the parameters are shown as
following:
