7 Parameter Overview
Here are overall parameters in NK280 general four axes system of manufacturers‘ access.
Parameters are listed according to their sequences under [All View] tab of [Machine Parameters (A)]
screen.
Name
Setting Range
Default
Value
When
Enabled
Refer-
ence
Manual High Speed
15000~15000 (mm/min)
3500
Immediately
3.9.3
Manual Low Speed
0 ~ Manual High Speed
(mm/min)
1500
Immediately
3.9.3
Dry Running Speed (G00)
Machining Speed ~ MAX Axial
Velocity (mm/min)
3500
Immediately
3.9.3
Machining Speed (GXX)
Z-axis Approach Speed ~ MAX
Axial Velocity (mm/min)
3000
Immediately
3.9.3
Pulse Equivalent (X)
0.0001~1 (mm/p)
0.001
After restart
3.2.2
Pulse Equivalent (Y)
0.0001~1 (mm/p)
0.001
After restart
3.2.2
Pulse Equivalent (Z)
0.0001~1 (mm/p)
0.001
After restart
3.2.2
Pulse Equivalent (A)
0.0001~1 (mm/p)
0.001
After restart
3.2.2
Workbench range upper
limit (X)
0~67108.8640(mm)
400
After restart
3.2.3
Workbench range upper
limit (Y)
0~67108.8640(mm)
400
After restart
3.2.3
Workbench range upper
limit (Z)
-100~67108.8640(mm)
0
After restart
3.2.3
Workbench range upper
limit (A)
-50~11712.7603(mm)
50
3.2.3
Workbench range lower
limit (X)
-67108.8640~Workbench range
upper limit (mm)
0
After restart
3.2.3
Workbench range lower
limit (Y)
-67108.8640~Workbench range
upper limit (mm)
0
After restart
3.2.3
Workbench range lower
limit (Z)
-67108.8640~Workbench range
upper limit (mm)
-100
After restart
3.2.3
Workbench range lower
limit (A)
-67108.8640~Workbench range
upper limit (mm)
-50
After restart
3.2.3
Change tool range upper
limit (X)
0~67108.8640(mm)
400
After restart
3.2.3
Change tool range upper
limit (Y)
0~67108.8640(mm)
400
After restart
3.2.3
Change tool range upper
limit (Z)
-100~67108.8640(mm)
0
After restart
3.2.3
Change tool range upper
limit (A)
0~11712.7063(mm)
0
After restart
3.2.3
Change tool range lower
limit (X)
-67108.8640~Change tool
range upper limit (mm)
0
After restart
3.2.3
Change tool range lower
limit (Y)
-67108.8640~Change tool
range upper limit (mm)
0
After restart
3.2.3
Change tool range lower
limit (Z)
-67108.8640~Change tool
range upper limit (mm)
-100
After restart
3.2.3
Change tool range lower
limit (A)
-11712.7603~Change tool
range upper limit (mm)
0
After restart
3.2.3
Axis output direction (X)
1: Positive direction
-1: Negative direction
1
After restart
3.2.1
Axis output direction (Y)
1: Positive direction
1
After restart
3.2.1
