WEIHONG 200 Series Manufacturer's Manual

上海维宏电子科技股份有限公司
Weihong Electronic Technology Co., Ltd.
- 146 - Specialized, Concentrated, Focused
Name
Setting Range
Default
Value
When
Enabled
Refer-
ence
-1: Negative direction
Axis output direction (Z)
1: Positive direction
-1: Negative direction
1
After restart
3.2.1
Axis output direction (A)
1: Positive direction
-1: Negative direction
1
After restart
3.2.1
Safety Height
0~5000 (mm)
10
Immediately
3.2.1
Single Axis Acc
0.001~100000 (mm/ s
2
)
1200
Immediately
3.9.3
Delay time of acute angle
motion
-(ms)
0
Immediately
-
Startup Speed
0~Z-axis Approach Speed (mm/
min)
100
Immediately
3.9.3
Rough Speed of
Calibration
1 ~ Rapid JOG Feedrate
(mm/min)
400
Immediately
3.9.3
Calibration Block
Thickness
0~100 (mm)
10
Immediately
3.6
X Coor of Fixed Cali Block
Negative Travel Limit (MCS) ~
Positive Travel Limit (MCS)
(mm)
0
Immediately
3.6
Y Coor of Fixed Cali Block
0
Immediately
3.6
Z Coor of Fixed Cali Block
-1.0
Immediately
3.6
Handwheel Output
Direction
-1: Opposed to axis output
direction
1: Same as axis output direction
1
After restart
3.14.2
Handwheel in strict
accordance with the pulse
counting
Yes: Valid
No: Invalid
No
After restart
3.14.2
Acceleration of handwheel
0~100000
200
After restart
3.14.2
Full Feedrate for G00
Yes: Fixed
No: Not fixed
Yes
After restart
3.9.3
Feedrate is Valid for
Manual Mode
Yes: Valid
No: Invalid
Yes
After restart
3.9.3
Use Default Speed
Yes: Valid
No: Invalid
Yes
Immediately
3.9.3
Use Default Spindle
Speed
Yes: Valid
No: Invalid
Yes
Immediately
3.9.3
Back to REF before
machining
Yes: Valid
No: Invalid
Yes
Immediately
3.3.2
Cancel REF Sign on
Estop
Yes: Valid
No: Invalid
Yes
Immediately
3.3.2
Is reset SVON when estop
Yes: Valid
No: Invalid
No
Immediately
3.3.2
MAX Angle of Joining
High Speed
0~180.001 (deg)
120
Immediately
-
Corner Trace
Pretreatment Options
0: Not disposed
1: Curve smooth
2: Arc smooth
0
Immediately
-
Corner tolerance
0~0.5 (mm)
0.1
Immediately
-
Connect speed look
ahead distance
0~0.05 (mm)
0.05
Immediately
-
Predicted segment No.
1~100
50
Immediately
3.9.3
Whether to Use S-type
Algorithm
Yes: Valid;
No: Invalid
1
Immediately
3.9.3
Plunge Speed Options
0: No limitation
1: Z Down Feedrate Limitation
valid with only Z-axis downward
0
Immediately
-
