WEIHONG 200 Series Manufacturer's Manual

上海维宏电子科技股份有限公司
Weihong Electronic Technology Co., Ltd.
- 92 - Specialized, Concentrated, Focused
3.18.3 Related Parameters
Parameter
Meaning
Setting Range
Turn On Radius
Compensation
Whether to enable tool radius
compensation function or not.
Yes: enable
No: not enable
Specify Cutter
Compensation Type
It specifies the cutter compensation
type. 1 for normal type, 2 for intersect
type and 3 for insert type.
1;2;3
Tool magazine capacity
The largest tool number that can be
saved in the tool magazine. To set the
corresponding tool coordinate, the
system needs rebooting after tool
magazine capacity modification.
1~20
Current tool No.
Tool No. being used
0~ Tool magazine capacity
Current Tool Pan No.
The current tool magazine No.
1~20
Tool change prompt
Whether the system will suspend and
prompt tool change when tool change
command is encountered
No: Invalid
Yes: Valid
T0 Handle Mode
0: invalid; 1: to be no-tool state; 2: first
tool index is 0
0;1;2
Tool change upper
position
The mechanical coordinate of Z axis
of the CT_UP position in tool change.
-
Tool change lower
position
The mechanical coordinate of Z axis
of the CT_DOWN position in tool
change.
-
X change tool position
The mechanical coordinate of X axis
of change tool position.
-
Y change tool position
The mechanical coordinate of Y axis
of change tool position.
-
X coordinate of tool
change ahead position
They specify the position where the
spindle starts decelerating before
entering tool magazine.
The position where the spindle starts
decelerating before entering tool
magazine.
-
Y coordinate of tool
change ahead position
-
Z coordinate of tool
change ahead position
-
Tool change speed
The feedrate used in tool change
process.
0.001~15000
Z axis CTup and CTdown
speed
The feedrate the spindle moves from
the CT_up position to CT_down
position.
0.001~3000
Traversing speed in/out
tool magazine
The feedrate when the spindle moves
into /out of tool magazine in tool
change.
0.001~3000
Tool change delay
Pause time in tool change.
0~600000
Move to origin position
after tool change
Whether to move to the origin or not
after tool changed.
Yes: move to the origin
No: not move to the origin
X axis machine
coordinate
The machine coordinate of X axis of
T1.
-
Y axis machine
coordinate
The machine coordinate of Y axis of
T1
-
Z axis machine
coordinate
The machine coordinate of Z axis of
T1
-
There are altogether 10 groups of coordinates info of tools. The above one is only an example.
