WEIHONG 200 Series Manufacturer's Manual

上海维宏电子科技股份有限公司
Weihong Electronic Technology Co., Ltd.
Specialized, Concentrated, Focused - 141 -
6.3.7 Wiring Diagram of FUJI Servo Driver
Signal Pin
+24V 6
ALM 8
SON 9
CLR 10
GND 15
A+ 1
A- 2
B+ 3
B- 4
C+ 5
SignalPin
P241
OUT115
CONT1 RUN
2
CONT2 RST
3
M2414
FFA9
*FFA10
FFB11
*FFB12
FFZ23
*FFZ24
Remark: twisted pair cable adopted for differential signal
transmission. Brake unavailable.
Weihong DB15 Driver Interface
Fuji FALDIC-β 26P HD Plug
C- 7
PLU+ 11
PLU- 12
DIR+ 13
DIR- 14
CA7
*CA8
CB20
*CB21
6.3.8 Wiring Diagram of HITACHI Servo Driver
Signal Pin
+24V 6
ALM 8
SON 9
CLR 10
GND 15
PLU+ 11
PLU- 12
DIR+ 13
DIR- 14
A+ 1
A- 2
B+ 3
B- 4
C+ 5
SignalPin
PLC2
ALM11
SON26
RS27
CM130
PLSP15
PLSN16
SIGP40
SIGN41
OAP21
OAN22
OBP46
OBN47
OZP23
OZN24
Z axis brake line
Weihong DB15 Driver Interface Hitachi ADA Servo Driver
BRK13
C- 7
CM234
PEN33
