WEIHONG 200 Series Manufacturer's Manual

上海维宏电子科技股份有限公司
Weihong Electronic Technology Co., Ltd.
Specialized, Concentrated, Focused - 21 -
2.2.2 Port Specification of Terminal Board
2.2.2.1 Standard 4-axis System
Group
Silk-printed
Name
Software
Definition
Description
External
power
+24V
DC 24V power
Terminal board should be powered by external
power supply.
COM
REF. point
signal
X0
X machine origin
Binary input, low level effective; connected to
home switch of X-axis.
Y0
Y machine origin
Binary input, low level effective; connected to
home switch of Y-axis.
Z0
Z machine origin
Binary input, low level effective; connected to
home switch of Z-axis.
W0
A machine origin
Binary input, low level effective; connected to
home switch of A-axis.
COM
Common port
Signal common port.
Limit signal
XLAM+
X positive limit
Binary input, low level effective; connected to
positive limit switch of X-axis.
XLAM-
X negative limit
Binary input, low level effective; connected to
negative limit switch of X-axis.
YLAM+
Y positive limit
Binary input, low level effective; connected to
positive limit switch of Y-axis.
YLAM-
Y negative limit
Binary input, low level effective; connected to
negative limit switch of Y-axis.
ZLAM+
Z positive limit
Binary input, low level effective; connected to
positive limit switch of Z-axis.
ZLAM-
Z negative limit
Binary input, low level effective; connected to
negative limit switch of Z-axis.
COM
Common port
Common port of digital signals.
Commonly
used input
SALAM
Spindle alarm
Binary input signal, connected to spindle alarm
switch.
OILAM
Oil level detection
Binary input signal, connected to sense switch of
oil level.
CUT
Tool sensor
Binary input signal, connected to tool sensor
signal (tool presetter signal).
GX57
Tool Over-travel
Protection
GX59
Cycle start
Connected to cycle start button.
GX60
Cycle stop
Connected to cycle stop button.
Spindle
control
SVC
Signal output of
analog voltage
(from 0 to 10V)
Actual spindle speed/MAX. spindle
speed=SVC/10V.
GND
Analog voltage
ground
SPIN
Spindle CW
Controlling the spindle to rotate forward.
SCOOL
Spindle cool
Connected to spindle coolant switch.
